RF Coaxial TNC Male Right Angle Clamp Connector For 5D-FB Cable

nterface	IEC 60169-17/CECC 22200
Electrical
Characteristic Impedance	50ohm
Frequency Range	DC-11GHz
VSWR	≤1.2 @DC-3GHz
Dielectric Withstanding Voltage	≥1500V RMS,50Hz,at sea level
Working Vlotage	500V RMS,50Hz,at sea level
Dielectric Resistance	≥5000MΩ
Contact Resistance	Center Contact ≤10mΩ	Outer Contact ≤2.5 mΩ
Mating	-
Mechanical
Durability	Mating cycles ≥500
Material and Plating
Parts Name	Material	Plating
Body	Brass	Ni
Insulator	PTFE	-
Center conductor	Phosphor Bronze	Au
Coupling nut	Brass	Ni
Back nut	Brass	Ni
Cable clamp	Brass	Ag
Thick washer	Brass	Ag
Thin washer	Brass	Ag
Gasket	Silicone Rubber	-
Environmental
Operating Temperature	-450ºC- + 85 ºC
Weatherproof Rate	IP67
RoHS (2002/95/EC)	Yes
