LR-JQX-13F-3Z
| Outline Dimension（L*W*H） | 31*27*35 | |
| Contact Form | 3A,3C | |
| Contact Resistance | 50m Ω | |
| Coil Voltage | 5~24VDC | |
| Pick-up Voltage | ≦ 75% | |
| Release Voltage | ≧10% | |
| Coil Power（W） | 1.5W | |
| Contact transfer | 10A | |
| Contact Rating | 10A 240VAC/30VDC | |
| Insulation Resistance | 100MΩ | |
| Dielectric Strengh | Between Open Contact | 1000VAC |
| Between Coil and Contact | 1500VAC | |
| Life | Electrical | 1*10⁵ |
| Mechanical | 1*10⁷ | |
| Temperature Range | -40~+70℃ | |
| Wiring diagran |  | |
| Mounting Holes（mm） |  | |
| Mounting Form | PCB/QUICK Terminal | |
| Weight | 47g | |
| Safty Approval | TUV | |
